High precison PS bowl making Thin Wall Injection Molding Machine for fast food box

VAINO INTERNATIONAL LIMITED

High precison PS bowl making Thin Wall Injection Molding Machine for fast food box

Brand Name : VAINO

Model Number : K2-320s

Certification : CE/ISO9001:2008

Place of Origin : Ningbo,China

MOQ : 1SET

Delivery Time : 15-25 working days after confirm order and received deposit

Packaging Details : Wooden pellet Wooden case(optional)

Contact Now

High precison PS bowl making Thin Wall Injection Molding Machine for fast food box

Fit for the Raw material and products as below:

  1. General packing products such as vacuum bottle, fast-food box, pudding box and etc all these made of PP PE PS material
  2. The high requested packing products made of PP,PE,ABS*PC,PS such as the shell of CD and DVD, telephone charger box and so on.
  3. Engineering products ,such as electronic connector, plastic precision gears and so on. all these made of POM,PA,PBT,PC material

SPECIFICATIONS

SPECIFICATIONS
DESCRIPTION UNIT K2-320s
INJECTION A B C
SHOT VOLUME CM3 1062 1231 1414
SHOT WEIGHT G 966 1120 1286
(PS) OZ 33.7 39.2 44.9
SCREW DIAMETER MM 65 70 75
INJECTION PRESSURE MPA 175 152 133
SCREW L:D RATIO 21:1 21:1 19.6:1
SCREW STROKE MM 320
SCREW SPEED (STEPLESS) R/MIN 0~150
CLAMPING UNIT
CLAMPING FORCE KN 3200
OPENING STROKE MM 615
PLATEN SIZE MM*MM 945*945
SPACE BETWEEN TIE BARS MM*MM 660*660
MOLD THICKNESS (MIN-MAX) MM 250~670
MAX.DAYLIGHT MM 1285
HYDRAULIC EJECTION STROKE MM 160
HYDRAULIC EJECTION FORCE KN 77
POWER UNIT
HYDRAULIC SYSTEM PRESSURE MPA 17.5/36.7
PUMP MOTOR(V/S) KW 30/36.7
HEATING CAPACITY KW 21.5
NUMBER OF TEMP CONTROL ZONES 5+(NOZZLE )
GENERAL
DRY-CYCLE TIME SEC 5
OIL TANK CAPACITY L 500
MACHINE DIMENSIONS MXMXM 6.8*1.6*2.2
MACHINE WEIGHT KG 13000


High precison PS bowl making Thin Wall Injection Molding Machine for fast food box
